CDI, the SPI who loved me

Posted by Antoine Sabot-Durand on Feb 20, 2016 | Comments

CDI users ask me very often why they should adopt CDI and stop using their old framework or way of doing their developments. The answer to this question can be found in advanced CDI stuff: extension mechanism and CDI SPI.

Yes, CDI true killing feature is not accessible out of the box and you have to dig into the spec to grab its power. Unfortunately, the way it’s introduced and explained in the specification document doesn’t make it particularly shine.

With this article and a coming one on portable extensions, I’ll try to fix that and help beginner users to get an overview of the power they’ll have if they invest time in learning CDI SPI.

I’ll try to show you all the aspects of the CDI SPI and how you can use part of it in your day to day work. In this article I’ll use the term "usual code" in opposition to portable extension code to differentiate standard development from development to extend CDI. At the end of the day you’ll see how much the CDI SPI loves developers ;).

What is this SPI?

CDI SPI is the introspection part of the spec allowing developers to access meta-information about CDI concepts (Beans, events, injection point, interceptors, etc…​)

While some of you may be more familiar with the term API (Application Programming Interface), the CDI specification is mainly built on a SPI concept (Service Provider Interface). So what’s the difference?

  • An API is the description of classes/interfaces/methods/…​ that you call and use to achieve a goal

  • An SPI is the description of classes/interfaces/methods/…​ that you extend and implement to achieve a goal

To make short, CDI provides interfaces that you implement (or that spec implementation implement for you) to perform a specific task. Access to these implementation are usually done through injection or event observation but you’ll have on the rare occasion to create your own implementation.

To ease the understand of the SPI, I’d like to split in 4 parts:

  • CDI entry points

  • Type meta-model

  • CDI meta-model

  • SPI dedicated to extensions

This division is a subjective approach I use to introduce elements of the SPI, it doesn’t reflect organisation of CDI packages or documentation.

Let’s explore these different parts

SPI providing CDI entry points

Usually, when you develop a Java EE application you don’t have to bother "entering" in CDI bean graph. It’s automatically done from the UI (via expression language), CDI event triggered automatically at boot time or EJB call.

But sometimes, you may need to access CDI from non CDI code or plug non CDI code to CDI beans at run time. This part of the SPI gives you the tools to do it.

entry points

BeanManager and CDI

In CDI 1.0 the only solution you had to access CDI bean graph was to retrieve the BeanManager from JNDI

BeanManager bm = null;
try {
    InitialContext context = new InitialContext();
    bm = (BeanManager) context.lookup("java:comp/BeanManager");
} catch (Exception e) {

The BeanManager is a central interface in CDI SPI, giving access to all meta-data and instantiated components in your application.

Checking its section in spec or its javadoc gives a complete overview of all the features it contains.

The main reason for developers to access CDI from non CDI code is to request a Bean instance to enter the CDI bean graph. Doing so with the BeanManager is a bit verbose.

BeanManager bm = null;
try {
    InitialContext context = new InitialContext();
    bm = (BeanManager) context.lookup("java:comp/BeanManager"); (1)
} catch (Exception e) {
Set<Bean<?>> beans = bm.getBeans(MyService.class); (2)
Bean<?> bean =  bm.resolve(beans); (3)
CreationalContext<MyService> ctx = bm.createCreationalContext(bean); (4)
MyService myService = (MyService) bm.getReference(bean, MyService.class, ctx); (5)
1 Retrieving BeanManager thru JNDI
2 retrieving all the beans having MyService in their type and the @Default qualifier
3 apply the ambiguous dependency resolution for the set of beans
4 create a CreationalContext to help contextual instance creation for complex use cases like circularities
5 get the instance

This verbosity is the proof that the BeanManager is and advanced CDI tool allowing very basic operation on CDI echos system. It’s obviously not the best solution if you just want to access an instance.

That’s why, in CDI 1.1 we introduced the abstract CDI class which use Java Service Loader to retrieve a concrete CDI class from the implementation.

CDI<Object> cdi = CDI.current();

CDI gives a faster access to the BeanManager with CDI.getBeanManager() method, but more interestingly, it provides a convenient way to request a contextual instance without using the cumbersome code with BeanManager.

As CDI extends Instance<Object> it naturally provides contextual instance resolution with programmatic lookup.

To make short accessing CDI in your non CDI code provides the same service than having the following injection in CDI code.

@Inject @Any Instance<Object> cdi;

Retrieving an instance becomes as simple as

CDI<Object> cdi = CDI.current();
MyService service =;


CDI 1.1 introduced an other nice feature to help you integrating CDI in non CDI code. The Unmanaged class allows you to apply some CDI operation to a non CDI class.

With it you can call lifecycle callbacks (@Postconstruct and @Predestroy) and perform injection on such class instance. Third party framework developers can then provide their non CDI class including injection point (remember @Inject is not part of CDI spec but AtInject spec) and Unmanaged can be used to get instances of this class.

For instance, imagine this class included in a non CDI archive.

public class NonCDI {

  SomeClass someInstance;

  public void init()  {

  public void cleanUp() {

You can obtain an instance of this class with injection point satisfied with this code

Unmanaged<NonCDI> unmanaged = new Unmanaged(NonCDI.class);
UnmanagedInstance<NonCDI> inst = unmanaged.newInstance();
NonCDI nonCdi = inst.produce().inject().postConstruct().get();

By checking the code in Unmanaged and UnManagedInstance classes you can see how other CDI SPI interfaces are used to provide this feature^

SPI for type meta-model

As all configuration in CDI is based on annotations, we need a mutable meta-model to create or modify existing configuration.

In an other world we could have rely on JDK for type representation and reflection, but as it is read only we had to create our own model in CDI.

type meta

The AnnotatedType interface is main element of this annotation centric type meta-model. other interfaces are abstraction or contained by it.

Defining an AnnotatedType let’s you put all annotations you need on the type, fields, methods or method parameters.

AnnotatedType are mainly used in portable extension They are constructed by the container from existing types.

As you can see, this model has no CDI specific feature, so if a third party developer decide to couple his framework to CDI he can allow his users to play with AnnotatedType to configure his framework

SPI dedicated to CDI meta-model

I already gave a good overview of the interfaces related to Bean meta model in my previous article, so I wont go back into detail on it.

bean meta

Just remember that while this meta-model is mainly used in portable extensions to declare custom beans, it can also be used in your bean to get introspection feature about the current bean, interceptor, decorator or the currently intercepted or decorated bean.

The rest of the CDI meta data SPI interfaces are below:

cdi meta

ObserverMethod and EventMetaData

ObserverMethod interface represent meta data for a given observer method and doesn’t have any usage outside a potable extension. So I’ll deal with in my next article on extensions.

EventMetadata is also related to events but at the opposite logic of EventMetadata, it is only used in usual code and never in an extension. You can inject it in your observer to get information about the event that triggered it.

For instance, you can use it to have stricter approach to observer resolution.

As I wrote in my event post, observer resolution for a given type and qualifiers set, also include an observer for any subclass of the event type and without any qualifier. You could use EventMetadata to restrict this rule by checking effective event type and qualifier like this:

public class MyService {
  private void strictListen(@Observes @Qualified Payload evt, EventMetadata meta) {
    if(meta.getQualifiers().contains(new QualifiedLiteral())
       && meta.getType().equals(Payload.class))
         System.out.println("Do something") (1)
1 this code will be executed only if event type is strictly Payload and its qualifiers contains @Qualified

Producer and InjectionTarget and their factories

Producer and InjectionTarget are also mostly used in extension. But if you took a look to Unmanaged presented above you may have seen that InjectionTarget can be used in usual code to perform some lifecycle operations an injection on a non CDI class.

As Unmanaged doesn’t allow you to perform injection on existing object you can use this code to do it yourself. This can be useful if you want to have object provided by a third party, perform injection in CDI way.

AnnotatedType<MyClass> type = beanManager.createAnnotatedType(MyClass.class);
InjectionTarget<MyClass> injectionTarget = beanManager.getInjectionTargetFactory(MyClass.class).createInjectionTarget(null);
CreationalContext<MyClass> ctx = beanManager.createCreationalContext(null);

MyClass instance = new Myclass;
injectionTarget.inject(instance, ctx);

CDI 1.1 introduced ProducerFactory and InjectionTargetFactory to resolve circular dependency issues when using Producer or InjectionTarget in an extension to create a new kind of Bean. I will detail them in my next post.

InjectionPoint meta-data

Last but not least in this SPI family: the InjectionPoint. This swiss-army knife is as much used in extension than in usual code. But in the later case you can only use it to get information on injection point related to @Dependent scoped bean. It’s the only way to guarantee the injection point uniqueness (i.e. the same @RequestScoped instance can be injected in multiple place). That’s the price to access InjectionPoint power.

Let’s check some nice way to use the InjectionPoint.

Using a qualifier to pass parameter to a producer

As InjectionPoint is used to get info about what’s being injected, info included in a qualifier can be used to decide what to return in a producer

First let’s create a qualifier with non binding member

public @interface HttpParam {
    @Nonbinding public String value(); (1)
1 This qualifier integrates a non binding member, that let us pass information to our producer

Then a producer for a dependent bean that analysis info at his injection point.

@HttpParam("") (1)
@Dependent (2)
String getParamValue(InjectionPoint ip, HttpServletRequest req) { (3)
  return req.getParameter(ip.getAnnotated().getAnnotation(HttpParam.class).value());
1 This producer defines a bean having String in its type set and qualified with our qualifier
2 Remember to use injection point in your bean must be in dependent scope.
3 this producer injects the InjectionPoint meta-data and the built-in HttpServletRequest bean

Finally we can use this producer by injecting the matching bean type and qualifier, with the parameter in the qualifier

String productId;

Analyze requested types a injection point

CDI does a great job to avoid type erasure and guarantee a powerful usage of parameterized types.

In the example below, we have a producer for a generic Map that use different implementations depending on the type of map values requested at the injection point.

class MyMapProducer() {

    <K, V> Map<K, V> produceMap(InjectionPoint ip) {
        if (valueIsNumber(((ParameterizedType) ip.getType()))) (1)
            return new TreeMap<K, V>();
        return new HashMap<K, V>();

    boolean valueIsNumber(ParameterizedType type) { (2)
        Class<?> valueClass = (Class<?>) type.getActualTypeArguments()[1];
        return Number.class.isAssignableFrom(valueClass)
1 this code retrieve the parameterized type defined at the injection point and send it to the test function
2 this test function will check the effective type of the second type prameter (type of the map values) and return true if this type inherit Number

With the code above @Inject Map<String,String> map will use an HashMap under the hood while @Inject Map<String,Integer> map will use a TreeMap. An elegant way to optimize or change behaviour without leakage in business code.


There are lot of features you can imagine to build with InjectionPoint and keep in mind that we only saw a few example in usual code. Imagine what you can do in an extension…​

SPI dedicated to extensions

Let’s end this SPI tour by a cliffhanger.

The following SPI classes are totally dedicated to extension development.

In fact they defined events type for each step in the container lifecycle (mainly the bootstrap part) where the portable extension magic occurs.

spi extensions

Let’s discover this magic in a coming post about extension.
